How it Works

The widest field-of-view and lightweight AR headset, for the masses


Cutting-edge micro-lED Image Source

In the world of AR, there are many competing display technologies, such as LCoS, OLED, and LBS. In this menagerie of displays, one novel technology - micro-LED’s, or uLED’s, stands out. uLED’s displays have the true black performance of OLEDs, are very bright, and don’t suffer from speckle artifacts like LBS systems do.

There’s just one problem - currently, large uLED area displays don’t exist, and full-color uLED panels have poor performance due to fabrication issues. In order to take advantage of currently manufacturable displays, we use a compact, custom-designed panel in conjunction with a scanning system and tightly integrated optics to create a high resolution area display - in effect, our tech is the ideal middle way between the flying spot of an LBS system and a conventional area display such as an OLED.

Even as uLED technology advances, our display will always retain the manufacturing advantage - it always consumes fewer resources to build a small line display than a large rectangular one. In fact, using current, manufacturable pixel pitches and panels, we can already achieve virtually unlimited resolution; we “only” have 8K per eye because display interface standards don’t allow for anything higher!



Novel Structured Geometric Waveguide Eyepiece

The goal of any AR optical system is simple - to get an image from somewhere on the user’s head to “out there”; that is, some distance (usually a few meters) in front of the wearer, superimposed on the the real world. Any AR system will have a few lenses and mirrors, and an eyepiece, or “combiner”, which serves as the final element in the relay.

The choice of eyepiece technology is the heart of a headset design; it strongly influences the form factor, field of view, and image quality of the system. Popular designs include diffractive waveguides, giant reflectors, and birdbath designs, all of which have their pros and cons. Diffractive waveguides are compact, but have a limited field of view, suffer from artifacts in bright light, are hard to mass produce, and are optically inefficient. Giant reflectors have a relatively wide field of view and are cheap to manufacture but, as their name implies, are very large - such headsets literally mount a smartphone screen to the user’s head. Birdbath designs are relatively compact and wide, but are heavy and extremely dark; because the light passes twice through 50% transmissive beamsplitters, over 75% of the light is lost.

Our system uses a structured geometric waveguide as the combiner. Like in a diffractive waveguide, light is coupled down the eyepiece via total internal reflection, but unlike a diffractive system, the structures in the eyepiece are explicitly much larger than a wavelength, which prevents colored ghosts in ambient light. Furthermore, the out-coupling elements are ordinary geometric optics, not holograms, which mitigates the narrow angle of acceptance from which diffractive elements suffer from. In addition, a careful multi-layer design allows the out-coupling elements to cover about 5% of the eyepiece’s area, allowing us to maintain very high transparency.



Easy-to-Use, cross-platform software Development Platform

In the end, the strength of a product depends on what its users do with it. This is especially true in an emerging field like AR, where rapidly advancing hardware innovations change possible applications overnight.

Kura’s unmatched transparency, field of view, and form factor enable applications that were previously impossible. For example, architectural visualization and automotive design clients benefit immensely from the wide field of view, which immediately allows them to see and interact with the entire model at arm’s range. Technical training and service applications greatly value the high transparency - in a potentially dangerous industrial setting, it would be unacceptable to obstruct the outside view. Likewise, collaboration and telepresence uses require a highly transparent headset to preserve eye contact and expressiveness. Moreover, our bright, high-resolution, and ghost-free image enables a whole new class of entertainment applications.

To enable our users to implement what they want without being held back, we provide a full suite of sensors, including cameras, eye tracking, head tracking, and depth tracking. We also provide API’s for integration with popular game engines such as Unity and Unreal, as well as lower-level access through OpenXR. Finally, we have several useful, off-the-shelf applications for common tasks such as 3D visualization and conferencing on which users can build.


AR Display and Optics Technologies Comparison

Structured Geometric Waveguide Diffractive Waveguide Birdbath/Freeform Prism Giant Reflector Reflective Waveguide Pin Mirror Holographic Reflector
Examples Kura Gallium Hololens, Magic Leap, WaveOptics, Digilens, Vuzix, Dispelix, Sony Nreal, 0Glass, Google Glass, Realwear, Hisene, Ned+, LLVision Mira, Realmax, Leap Motion North Star, Meta, Ximmerse, Dreamworld, Lenovo Mirage AR Lumus, Lochn, Optivent Letinar Focals By North
Field of View Very Wide (140-150°) Narrow (10-55°) Narrow (10-55°) Medium/Wide (50-100°, depends on the size) Narrow (40-55°) Medium (10-80°) Very Narrow (10°)
Transparency High (95%) Very Low (<25%, filter required due to dim image) Very Low (<25%) Low (20-50%) Medium (40-85%) High (80-95%) High (~90% or higher)
Brightness/Outdoor Usability High Low Medium Low Medium Low Medium
Contrast High Medium Medium/High (depends on image source) Low Low Medium Medium
Size Compact Medium Medium Large Compact Compact Compact, but FOV is very narrow
Depth of Field * Unlimited 1-2 discrete focal planes 1 focal plane 1 focal plane 1 focal plane Unlimited 1 focal plane
Mass Producibility * High Low Medium High Low High Medium

Depth of Field: Typical AR headsets relay the image to one or two discrete focal planes. This results in what is called “accommodation-vergence mismatch” - for example, depth cues and parallax may suggest that a virtual object is 10 meters away, but the wearer’s eyes are need to focus 2 meters away to see a sharp image. Accommodation-vergence mismatch can lead to eyestrain and discomfort after prolonged periods of usage. A select few technologies (our’s and Letinar’s pin mirrors) have unlimited depth of field - the in-focus regions extends from a few centimeters in front of the wearer all the way to infinity.

Mass Producibility: The manufacturability of a design largely depends on its material and tolerance requirements. Systems that can leverage well-developed, large-scale manufacturing techniques and automated assembly will be much cheaper than those requiring niche and exotic manufacturing processes and precision hand-assembly. For example, molded plastic lenses cost next to nothing thanks to the smartphone camera industry, whereas freeform glass prisms and diffractive waveguides are rather costly owing to the novelty and low volume of their respective processes. Manufacturing advances over time, but there is always strong value in a product that can be manufactured now, rather than a product that might be manufacturable years from now.
